P2 DSP Pro Technical Specs |
| DSP Chip |
ADAU1463 |
| DAC Chip |
6 x ESS 9038Q2M |
| ADC Chip |
2 x ES9840Q |
| Opamp |
NJM4580 & OPA2604 |
| Capacitors |
High Temperature for High Reliability to 105°C electrolytics and WIMA film Caps |
| Music Formats |
Hi-Res: DFF / DSF / DSD Up to 256, Hi Res Uncompressed: WAV / FLAC / APE / AIFF / AIF, Compressed: MP3 / AAC / OGG / WMA |
| Music Inputs |
USB 2.0 Host x 4 aptX-LL/AptX HD Optical (to 96/24bit) |
| Control Inputs |
BT Wireless Player Remote, Wi-Fi Mobile App, Optional Wired Panel controller w/IPS Display Screen |
| PC Connection |
USB B |
| Processing Functions (See delay below) |
Crossover Frequency: 20Hz ~ 20kHz @ 1dB steps, Master Gain: 0 ~ 60dB, Channel gains: -20dB ~ +5dB Polarity: Phase Reversal 0 or 180, EQ filters Q 0.5 ~ 15 @ 0.1 steps, Input Mixer, Three Linking Functions: Volume Linking- Absolute or Relative, EQ Linking - Relative or Absolute, Crossover Linking - With EQ link on, Freq Link button will link crossovers |
| Delay |
0 ~ 20ms / 0.02ms stops |
| Output EQ |
EQ bands: All Channels 31 @ ± 15dB in 0.1dB Steps, Filter Functions: Peak / High Shelf / Low Shelf / 1st order All Pass/ 2nd Order All Pass |
| Crossover |
Butterworth & Bessel: 6, 12, 18, 24, 30, 36, 42, 48dB / Linkwitz: 12, 24, 36dB |
| XO Phase Rotation |
Variable Phase shift at HP and LP filters from 0° ~ 359° |
| Inputs |
8 x Hi / 2 x RCA / BT |
| Input EQ |
EQ bands: All Channels 5 bands @ ± 15dB in 0.1dB Steps Filter Functions: Peak / High Shelf / Low Shelf / 1st order All Pass/ 2nd Order All Pass Input Delay: 0 ~ 10ms in 0.02 Steps |
| Frequency Resp: |
20Hz ~ 40kHz |
| Operating Voltage |
11V ~ 16V |
| Input Sens (V) RCA |
4V |
| Input Sens (V) Hi |
24V |
| RCA Out Voltage |
12 x 4V |
| RCA Out Specs |
THD+ Noise < 0.003 S/N Analog input ⧁ 108dB S/N Digital Input ⧁ 111dB |
| Amp Outputs | THD+Noise <0.03 S/N >100dB |
NA |
| Dimensions (mm) |
241 x 180 x 50 |
| Start-Stop ready |
Yes |
| EPS (Intelligent High-Level Input-Error Protection System) |
Yes |
| Finish |
Gold Anodized Aluminum |
| Auto Turn On via DC Offset or Signal Sensing |
Yes |
| Remote Turn on Output |
Yes |
| Clipping LED’s |
No |
| Built in Bluetooth |
aptX |
| Built In Wifi |
Yes |
| THD+Noise RCA |
0.003% |
| S/N ratio RCA |
108dB Analog / 111dB Digital |
| THD+Noise Amplifier |
0.02% |
| S/N ratio Amplifier |
NA |
| Fuse Rating |
10A |
| Input impedance: No Impedance adaptor needed |
6 Ohm High Level |
| Controller |
BT Wireless Player Remote, Optional Wired Panel controller w/IPS Display Screen, Wi-Fi Mobile App control |
| Input Mixer |
Yes |
| Presets |
8 |
| Software Interface |
PC 32bit W7 and up |
| All Pass filters at input and output EQs |
Both 1st Order and 2nd Order |
| Navigation Mode w/ Input Priority |
Yes |
| Automatic Mode Switching Mixer |
Yes |
| Password Available |
Yes |
| Analog Noise Gate |
Yes |
| Variable Power Off Delay |
Yes |
| Seven DAC rolloff choices for ESS 9038 |
No |
